雙滾珠
| 規格 | ||
| 產品型號 (尺寸與顏色): | 120 x 120 x 25 mm | |
| ACC-FAN-2BALL-12 | (黑) | |
| 140 x 140 x 25 mm | ||
| ACC-FAN-2BALL-14 | (黑) | |
| 轉速 (R.P.M.): | 1,200 RPM ±10% | |
| 風流 (CFM): | (120mm)45 CFM ±10% | |
| (140mm)60 CFM ±10% | ||
| 空壓 (mmH2O): | (120mm)1.66 mmH2O ±10% | |
| (140mm)1.43 mmH2O ±10% | ||
| 噪音: | < 16 dBA | |
| 軸承類型: | 雙滾珠 | |
| 風扇平均壽命: | 50000Hrs/25℃ | |
| 電壓: | 12 VDC | |
| 電流 (Ampere): | 0.4A | |
| 負載功耗: | 4.8W & +/ - 10% | |
| 安規認證: | CE / TUV / UL | |
| 接頭: | 4 PIN | |
