SILeNt

Specifications

Model (Dimension & Color):

80 x 80 x 25 mm

ACC-FAN-SL8

(Black)

ACC-FAN-SL8.14B

(Blue LED)

120 x 120 x 25 mm

ACC-FAN-SL12

(Black)

ACC-FAN-SL12.1

(Transparent)

ACC-FAN-SL12.14B

(Blue LED)

140 x 140 x 25 mm

ACC-FAN-SL14

(Black)

ACC-FAN-SL14.1

(Transparent)

ACC-FAN-SL14.14B

(Blue LED)

Speed (R.P.M.):

(80mm)  1,600 RPM ±10%

(120mm)1,200 RPM ±10%

(140mm)1,000 RPM ±10%

Air Flow (CFM):

(80mm)   30 CFM ±10%

(120mm) 45 CFM ±10%

(140mm) 60 CFM ±10%

Air pressure (mmH2O):

(80mm)  1.71 mmH2O ±10%

(120mm)1.66 mmH2O ±10%

(140mm)1.43 mmH2O ±10%

Fan Noise Level (dBA):

 < 19 dBA

Bearing Type:

Sleeve

Fan Life Expectancy:

20000Hrs/25℃

Voltage:

12 VDC

Current (Ampere):

(80mm)   0.2A

(120/140) 0.4A

Input (Watt):

(80mm)   2.4W & +/ - 10%

(120/140) 4.8W & +/ - 10%

Safety:

CE / TUV / UL

Connector:

2 PIN
