Manganese 80%

Specifications

Model:

AP-450MG

AP-550MG

AP-650MG

Type:

Intel Form Factor ATX V2.2/2.3(EPS12V2.91)

Input Voltage:

110/220Vac

Input Current:

5.4A@110Vac, 2.7A@220Vac (AP-450MG)

6.6A@110Vac, 3.3A@220Vac (AP-550MG)

7.8A@110Vac, 3.4A@220Vac (AP-650MG)

InputFrequencyRange:

47-63Hz

Output Capacity:

450W(AP-450MG)

550W(AP-550MG)

650W(AP-650MG)

Fan:

Sleeve Bearing Fan

Power Good Signal

100~500ms

Hold Up Time:

>17ms

Efficiency:

>80%

MTBF:

>100,000 小時

Protection:

OVP / UVP / OPP / OTP / SCP

Dimension:

150 (W)x 140(D) x 86(H)mm

Operation Temperature:

0~40°C (Nominal Input Voltage)

Safety:

CE / FCC / CB / TUV / FIMCO / NEMKO / BSMI / CCC

Connector:

20+4 PinMBx 1

4+4 Pin+12V 8P x 1

6+2 Pin PCI-e x 1

6 Pin PCI-e x 0 (AP-450MG)

6 Pin PCI-e x 1 (AP-550MG, AP-650MG)

SATA x4 (AP-450MG)

SATA x6 (AP-550MG, AP-650MG)

4 Pin Peripheral x 3 (AP-450MG)

4 Pin Peripheral x 5 (AP-550MG, AP-650MG)

4 Pin Floppy x 1

Warranty:

3 years
